Overview
PNY CS900 is the ideal solution for a mainstream solid state drive (SSD) upgrade from a hard disk drive (HDD). The CS900 delivers all the most sought after features at an excellent value, and is designed for an easy and cost-effective HDD replacement in the PC system to help realize faster boot times, quicker application launches and better overall system performance. With no moving parts, PNY CS900 is highly durable, less likely to fail, and features a 3-Year Limited Warranty or TBW*.
Usable Capacities | 256GB/ 500G/ 1TB/ 2TB |
---|---|
NAND Components | 3D NAND |
Interface | PCIe Gen 3x4 NVMe 1.3 |
Form Factor | M.2 2280 |
Package Dimensions (L×W×H) | 123 x 85 x 4.3 mm |
Product Dimensions (L×W×H) | 22 x 80 x 2 mm |
Weight | 6.6g |
Max Sequential Read* |
256GB: Up to 1700MB/s
500G: Up to 2200MB/s 1TB/ 2TB: Up to 2400MB/s |
Max Sequential Write* |
256GB: up to 1100MB/s
500GB: up to 1200MB/s 1TB/ 2TB: up to 1750MB/s |
TBW | 256GB: 150; 500GB: 110; 1TB: 240; 2TB:480 |
PCIe Link Power Management | APST, ASPM, L1.2 |
Operating Temperature | 0°C to 70°C |
Storage Temperature | -40°C to 85°C |
Certifications | BSMI, CE, FCC, KCC, VCCI, REACH, RoHS |
MTBF | 2 Million Hours |
Error Correction Code | Less than 1 sector per ten quadrillion bits read |
Product Health Monitoring | Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T) |
Full End-to-End Data path protection | Supported |
Performance Optimization | TRIM (requires OS support) |
Warranty | 3 years |
