Name: NETGEAR XS716T 16-Port 10G Ethernet Smart Managed Pro Switch - with 2 x 10Gigabit SFP+
Brand: Kaira Mauritius
SKU: XS716T-100NES
Availability: InStock

NETGEAR XS716T 16-Port 10G Ethernet Smart Switch - Managed, with 2 x 10 Gigabit SFP+, Desktop or Rackmount, and Limited Lifetime Protection

Centre de services local
Options de livraison disponibles

As a leading provider of network equipment for SMBs, NETGEAR® understands the importance of reliable and high performance networks. With the growth of virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, SMB networks need to extend beyond simple reliability to higher speed and performance.

The 10-Gigabit Smart Switch series from NETGEAR presents the right solution for this requirement; delivering unprecedented non-blocking 10-Gigabit bandwidth at an affordable cost. The NETGEAR XS708T, XS712Tv2, XS716T, XS728T, and XS748T are powerful Smart Switches that come with 8, 12, 16, 24, or 44 10-Gigabit Copper ports and either 2 Shared (Combo) Copper/SFP+ ports (XS708T/XS712Tv2/XS716T) or 4 additional Dedicated SFP+ ports (XS728T/ XS748T) for 10G Fiber links.

The NETGEAR 10-Gigabit Smart Switches are purposely designed as a cost-effective way to provide 10G connections to 10G-capable servers and NAS (Network Attached Storage) systems. They can be used at the “center of a small business network” or as an aggregation/ access switch in a larger organization including workgroup access, connecting to a 10-Gigabit NETGEAR Fully Managed Switch on one end and extending the 10G connections to the edge.

The XS708T, XS712Tv2 and XS716T are also ideal for smaller workgroups that need high bandwidth for sharing, collaborating, editing, and publishing high-density content like video or animation

Plus de 10-Gigabit Switching

NETGEAR 12 Empty Slot Modular Stackable Managed Switch with 8-port 10G and 2-port 40G expansion cards

NETGEAR XS724EM-100EUS 24-Port 10G/Multi-Gigabit Plus Switch with 2 Dedicated SFP+ Ports

NETGEAR XS724EM 24-Port 10G/Multi-Gigabit Plus Switch with 2 Dedicated SFP+ Ports

Épuisé

NETGEAR MS510TXM 8-Port Multi-Gigabit/10G Ethernet Smart Switch with 2 SFP+ Ports

NETGEAR 8-Port 10G Multi-Gigabit Ethernet Smart Switch (MS510TXM) - Managed, 8 x Multi-gig Ports, 2 x 10G SFP+, Optional Insight Cloud Management

Épuisé

NETGEAR 5-Port Gigabit Ethernet Plus PoE Pass-Throu/PoE Power Down Switch (GS105PE) with 2-Port PoE out Ports

NETGEAR XS508M 8-Port 10G Multi-Gigabit Ethernet Unmanaged Switch

NETGEAR XS505M 5-Port 10G Multi-Gigabit Ethernet Unmanaged Switch

Retour à 10-Gigabit Switching

Specifications Product Datasheet Installation Guide User Manual

Features

Traffic Management

Auto Negotiation of speed and duplex modes

IEEE 802.3x Flow Control

Dynamic MAC address management

IEEE 802.1Q-based VLAN

Auto Voice VLAN

Auto Video VLAN (selected models)

VLAN routing (selected models)

QoS based on WRR, strict priority, or both

Port-based and IEEE 801.2p-based QoS

TCP/UDP-based QoS

DiffServ

IPv4 and IPv6-based QoS (selected models)

DSCP Support

Rate Limiting (ingress, or egress)Link Aggregation and LACP

Switch Management

Web browser-based management GUI

Smart Control Center Software for multi-switch management

IP Access List

IPv6 Management

Configurable Management VLAN

SNMP v1/v2c and v3

Standard MIBs (RFC1213, RFC1643, and RFC1493)

RMON group 1, 2, 3, 9

Firmware Upgrade through Smart Control Center (TFTP)

Firmware download (to switch) and upload (to server) through TFTP/HTTP

Configuration and Image Upload (to PC) through HTTP

Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)Memory & FLASH log Syslog (server) System password protection

Memory & FLASH log

Syslog (server)

System password protection

Specifications

Product Number

XS716T

Gigabit ports

10-Gigabit copper ports

16 10GBASE-T copper

SFP ports

2 SFP+ 1000/10GBASE-X fiber ports (shared)

Number of PoE ports

PoE+ (802.3at)

Total PoE Power budget (Watts)

8 PoE+ (55W)

Max MAC entries

Buffer size

2 MB

MAC address database size

16K

VLAN (# supported)

512

Number of LAGs & number of members

8 LAGS with max 8 members in each LAG (LACP)

Number of priority queues

Access Control Lists (ACLs)

100 shared for MAC, IP and IPv6 ACLs

IPv4 Static routes

IPV6 Static routes

Power supply

Internal 100-240VAC 50-60Hz

Max power consumption (Watts)

96 W

VLAN routing

Yes

Dynamic VLAN assignment

Yes

MLD Snooping

Yes

Static route

Yes (32)

Host ARP table

512 ARP

EEE

Yes

DoS Prevention

Yes

Internal/External

External DC 54V 1.25A

Max consumption (Watts)

15.1W

FAN

Acoustic Noise Level @25C (dBA)

29.1 dBA

Operating Temperature

-5° to 55°C (23° to 131°F)

MTBF

276,832 hours

Electromagnetic compliance (A or B)

Class A

Physical Specification

Dimensions: 236 x 101 x 27mm, ( 9.3 x 4.0 x 1.1in)

Weight : 0.61kg, ( 1.34lb)

Warranty

Limited Lifetime Hardware Warranty
