WAX333: NETGEAR® Insight Managed WiFi 6 AX3000 Dual-band Access Point
SKU: WAX333-100APS-1
Powerful Business WiFi
• Ultimate speed and capacity with WiFi 6
• Enterprise level security with WPA3 and 8 separate wireless networks (SSIDs)
• High speed and easy wiring with one Gigabit Ethernet port with PoE
• Mesh capabilities for seamless roaming and highly scalable coverage areas
• Monitor and manage your network from anywhere with NETGEAR Insight, a user-friendly cloud monitoring and management cloud portal and app
NETGEAR INSIGHT REMOTE MANAGEMENT
Manage locally or remotely through the Cloud for simple yet powerful control of your network anytime, anywhere. Includes 3-year subscription.
POWERFUL BUSINESS WIFI
Faster and more reliable WiFi due to higher throughput and more coverage with the use of both 2.4Ghz and 5Ghz bands simultaneously.
GIGABIT SPEED
One Gigabit Ethernet port with PoE for quick and simple deployment.
SEAMLESS MESH WIFI
Seamlessly expand your network with any mesh-connected Insight access points.
COMPLETE COVERAGE
3-pack access point bundle provides extensive coverage and eliminates dead zones.
8 WIRELESS NETWORKS (SSIDS)
Separate and secure networks for admin, guests, employees and IoT devices.
BUSINESS-LEVEL SECURITY
WPA3 for the highest level of WiFi connection security.
SEPARATE VLANS
Keep admin, employee, and guest traffic safely separated and segregated.
EASY SET UP
Set up, configure, and manage with NETGEAR Insight and mobile app.
FLEXIBLE MOUNTING
Easy to securely install on a wall or ceiling with included mounting hardware.
Physical Specification
Dimensions (W x D x H) : 160 X 160 X 30 mm (6.30 X 6.30 X 1.18 in)
Weight : 0.38kg (0.83lb)
Physical Specification
WiFi Standard : IEEE® 802.11ax (WiFi 6)
Wireless Mode (Transmit x Receive) : 2.4GHz is 2x2, 5GHz is 2x2
OFDM/OFDMA : OFDM and OFDMA
Multi-User MIMO : Bidirectional MU-MIMO
Maximum Theoretical Throughput : AX3000, 3Gbps
Theoretical Throughput per Band : 5GHz: 2400Mbps; 2.4GHz: 600Mbps
Antenna Gain : Internal 2.9/2.8dBi (2.4GHz/5GHz)
Ports : 1 x Gigabit Ethernet
Power over Ethernet (PoE) : Yes, PoE
PoE
Power Consumption : 12.8W
# of Max Users : 250
# of Concurrent Users : 30
Fast Roaming : Yes
Security : WPA/WPA2/WPA3
SSID wireless networks : 8
Management : NETGEAR Insight Remote/Cloud Management (3-year subscription included), Local Web-based GUI, and Mobile app.
What's in the box
3 x WAX333 Access Points
Wall/ceiling mount kit
Installation guide
