Name: NETGEAR GSM4248PX 40x1G PoE+ 960W and 8xSFP+ Managed Switch
Brand: Kaira Mauritius
SKU: GSM4248PX-100EUS-1
Availability: InStock

NETGEAR GSM4248PX 40x1G PoE+ 960W and 8xSFP+ Managed Switch

Style

GSM4248PX-100AJS

GSM4248PX-100EUS

Centre de services local
Options de livraison disponibles

[{"id":43640761188528,"title":"GSM4248PX-100AJS","option1":"GSM4248PX-100AJS","option2":null,"option3":null,"sku":"GSM4248PX-100EUS-1","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"NETGEAR GSM4248PX 40x1G PoE+ 960W and 8xSFP+ Managed Switch - GSM4248PX-100AJS","public_title":"GSM4248PX-100AJS","options":["GSM4248PX-100AJS"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":43640761221296,"title":"GSM4248PX-100EUS","option1":"GSM4248PX-100EUS","option2":null,"option3":null,"sku":"GSM4248PX-100EUS-2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"NETGEAR GSM4248PX 40x1G PoE+ 960W and 8xSFP+ Managed Switch - GSM4248PX-100EUS","public_title":"GSM4248PX-100EUS","options":["GSM4248PX-100EUS"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

The NETGEAR AV Line of M4250 Switches, developed and engineered for audio/video professionals with dedicated service and support. M4250 has been built from the ground up for the growing AV over IP market, combining years of networking expertise in AV with M4300 and M4500 series with best practices from leading experts in the professional AV market. AV codecs generally use 1Gbps or 10Gbps per stream and the AV Line of M4250 targets the widespread 1Gbps codecs. PoE+, Ultra90 PoE++ and rear-facing ports ensure a clean integration in AV racks. M4250 switches come pre-configured for standard audio and video signals.

When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante,Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately. For video the M4250 offers profiles for NVX, AMX, Q-SYS, NDI, Dante etc. as well as audio/ video/control mixed profiles. When multiple switches are used, NETGEAR IGMP PlusTM brings automation for you to just connect them together, or with M4300 and M4500 switches.

Plus de ProAV / AV over IP

NETGEAR AV Line M4250-8G2XF-PoE+ (GSM4210PX) 8x1G PoE+ 220W and 2xSFP+ Managed Switch

NETGEAR AV Line M4250-9G1F-PoE+ (GSM4210PD) 8x1G PoE+ 110W 1x1G and 1xSFP Managed Switch

NETGEAR AV Line M4250-10G2F-PoE+ (GSM4212P) 8x1G PoE+ 125W 2x1G and 2xSFP Managed Switch

NETGEAR AV Line M4250-10G2XF-PoE+ (GSM4212PX) 8x1G PoE+ 240W 2x1G and 2xSFP+ Managed Switch

NETGEAR AV Line M4250-10G2XF-PoE++ (GSM4212UX) 8x1G Utra90 PoE++ 802.3bt 720W 2x1G and 2xSFP+ Managed Switch

NETGEAR AV Line M4250-12M2XF (MSM4214X) 12x2.5G and 2xSFP+ Managed Switch

Retour à ProAV / AV over IP

Specifications Data Sheet Installation Guide User Manual

Features

Pre-configured for out-of-the-box use

NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations

Dedicated AV web-based GUI interface

Unique interface designed for the AV professional with color-coded, port-based profiles

Profiles for common audio protocols

Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license

Video profiles built-in

Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed

Unique Automatic Configuration

Auto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology

Easier configuration with new AV GUI

The AV-oriented, web-based GUI permits factory or user-specified profiles to be assigned to individual ports as needed.

Use in noise-sensitive environments

Adjustable fans can be turned off if certain conditions are met. Even the default Quiet mode is quieter than most other switches

Get up and running fast with little engineering time required

Our NETGEAR IGMP Plus^{^TM}feature is set from the factory to ensure out-of-the-box functionality for most AV over IP installations.

Multiple mounting options provide ultimate flexibility

Threaded mounting holes sized to industry standards are built into the chassis for mounting behind a display or clamped to a truss.

Specifications

Product Number

GSM4248PX-100EUS

Primary Port Speed

1 Gigabit

Number of Ports

48 (40x 1G PoE+, 8x SFP+)

PoE Ports / Budget

40 PoE+ (30W/port), 960W Budget

IGMP Support

Enhanced (NETGEAR IGMP Plus™)

Jumbo Frame Support

Yes, up to 12kb

AVB Support

Yes. Electronic license required, activation key sent via email (AVB4248PX-10000S).

Acoustics

Fanless or 59dB@25ºC

Power Consumption

With PoE: 1197W/4086.56Btu/hr

Without PoE: 89.2W/304.53Btu/hr

Standby without any port connection: 74.5W/254.34Btu/hr

Physical Specifications

Dimensions (WxDxH) : 440 x 400 x 43.2 mm

Weight : 6.31 kg (13.91lb)

Product Contents

M4250-40G8XF-PoE+ (GSM4248PX)

Power cord(s)

Console USB Type-C and RJ45-DB9 cables

Rack-mounting standard brackets

Longer brackets for recessed mounting

Rubber footpads for tabletop installation

Installation guide

Warranty

Limted Lifetime Warranty
